Hot Selling PCB Board OEM Double Layer Printed Circuit Boards Fr4 PCBA Quick Prototyping EMS Turnkey Manufacturer
PRODUCT SPECIFICATION：
| Base Material: | FR4-TG140 | Surface Finish: | HASL(Lead Free) |
| PCB Thickness: | 1.6mm | Solder Mask: | Green |
| PCB Size: | 25*76mm | Silkscreen: | White |
| Layer Count: | 1/L | Cu Thickness | 35um(1oz) |
What files are required to produce your PCBs:
1. PCB files (Gerber files).
2. The specific quantity.
3. PCB thickness,Material, Copper thickness, Surface finish,Solder mask color or any other requirements.
For PCB assembly, the more files are required as below:
1. Bom list (bill of material)
2. Centroid files (Pick & Place files)
3. Assembly drawings,
4. Extra requirement for assembly.
Surface Finish Process:
ENIG(Immersion Gold):
Immersion gold process deposits a nickel- gold coating with stable color, good brightness, flat coating and good solderability on the surface of the printed circuit, the cost is relatively more expensive.
HASL (Lead Free):
The flatness is insufficient, but HASL is low cost. Due to environmental protection requirements, there is a requirement for lead free.
HASL (Lead Free) process is widely used by customers.
OSP:
Cover a layer of anti- oxidation protective film on the copper surface, the film thickness is uniform, the cost is low, but it is difficult to withstand multiple soldering.
WHY US:
1. Lower your cost: Turnkey PCBA Assembly; BOM Solution To Reduce The Cost; Professional Advice For Your Design Optimization.
2. Quality Assurance: ISO14001,IATF16949,UL Certificated; 100% AOI/E-Testing/X-ray/Software Programming and Function Test Supported.
3. On Time Delivery: Real- time Order Status Update; Transparent Production process Step; 99% On- time Shipping By DHL/ UPS/ FeDex/ TNT.
4. Best Customer Service: 24 Hours Online; Timely After- sales Feedback In 12 Hours; Professional Technical Support.
Main Product:
We’ve exported PCBs for more than ten years,support both prototyping and mass production.
1. 1- 32 Layer PCB Production(No MOQ.)FR-4, FPC board ,Aluminum plate,Heavy copper,HDI.
2. Components Sourcing.
3. Quick- turn Prototype and SMT&THT Assembly with high quality.
4. Precision Metal Parts Machining.
PCB Capabilities:
| Layer Counts | 1- 32 layers |
| Base Material | FR- 4, Polyimide, Metal base (Aluminum, Copper), High Frequency (Rogers, Teflon,PTEE), Hybrid, etc. |
| PCB Type | FR- 4 Rigid PCB, Aluminum PCB, Copper- based PCB, HDI, FPC, Rigid- Flex PCB, High- Frequency PCB, Rogers PCB, Thick copper PCB, Halogen- Free PCB, etc. |
| PCB Thickness | 0.1mm- 10mm |
| Copper Thickness | 1/ 2oz-6oz (18um-210um) |
| Board size | 500mm * 1500mm |
| Min Tracing/Spacing | 0.075mm/ 0.075mm (3mil/ 3mil) |
| Min drilling Hole | Mechanical drilling: 0.15mm (6mil), Laser drilling: 0.1mm (4mil) |
| Solder Mask | Green, Matt Green, Black, Matt Black, White, Red, Yellow, Blue, Purple, etc. |
| Silkscreen color | White, Blue, Black, Red, Yellow |
| Surface finish | HASL (Lead- free), Immersion Gold (ENIG), Immersion Tin, Immersion Silver, OSP, Carbon oil, etc. |
| Special Techniques | Impedance Control, Gold Fingers, Blind/ Buried vias PCB, Peelable solder mask, Half- holes, Via- in- Pad and Countersink hole, etc. |
